Bluetooth chip: Jie Li 5.3, transmission distance 10 meters
Input method: Bluetooth + AUX + U disk / sound card
Number of channels: 2.0, left channel + right channel
Amplifier chip: original TPA3255
Protection mechanism: input undervoltage, overheating, overcurrent, short circuit protection, no input reverse connection protection, positive and negative poles cannot be reversed!
Adapter power supply: working voltage range 18-50VDC, limit 53V, recommended voltage 36-48V, current 10A or more DC power supply
Power: single channel 300w@50V, 4 ohms; 160W@50V, 8 ohms; the higher the voltage, the smaller the resistance, the greater the output power
AC/DC12-16V power supply, distinguish between AC and DC input terminals. L, G, R: These are the dual-channel input terminals of the driver board, which can be connected to the audio of mobile phones, computer sound cards, preamplifiers and other audio source devices (the signal is the signal that the headphones can hear), and the amplifier output terminal to get the signal. When wiring, L, G, and R correspond to the left, ground, and right channels of the audio source device respectively. If the input is a mobile phone, computer sound card, preamplifier and other audio sources, please turn the dip switches 1 and 3 to the ON end. 1. AC/DC12-16V power supply, distinguish between AC and DC input terminals
L, G, R: This is the dual-channel input terminal of the driver board, which can be connected to the audio of mobile phones, computer sound cards, preamplifiers and other audio source devices (the signal is the signal that can be heard by headphones), and the output of the power amplifier. When wiring, L, G, and R correspond to the left, ground, and right channels of the audio source device respectively. If the input is a mobile phone, computer sound card, preamplifier and other audio sources, please turn the dip switches 1 and 3 to the "ON" end. If the input is the output of the power amplifier, please turn the dip switches 2 and 4 to the "ON" end. The signal will be compressed 11 times. Note that the dip switches 1 to 4 cannot be turned to the "ON" end at the same time.
The adjustable potentiometer "100R-V" is used to adjust the brightness of the vu meter backlight
The adjustable potentiometers "50k-1" and "50k-2" control the pointer jump amplitude of VU meter 1 and VU meter 2 respectively
Made of high-quality glass fiber ABS material
The driver board components are finely manufactured and durable
Stable performance makes the VU meter better, the pointer swings quickly, the response is sensitive, the wide range voltage stabilization circuit, and the working performance is more stable
This driver board supports low access, has adjustable brightness and darkness backlight, and intelligent drive
Dual SIM Compatibility: Supports testing two SIM cards simultaneously, making it convenient for users to test different cards' functionality and status quickly.
No complicated setup or software installation is required; insert the card and start testing immediately, making it user-friendly.
Quick Response: Test results are displayed almost in real-time, saving users time and increasing work efficiency.
Multi-functional Testing: Not only detects basic SIM card functions but also supports testing the signal strength and stability of the SIM card.
Portable Design: Compact and lightweight, easy to carry, making it suitable for mobile device repair engineers and phone enthusiasts to use anytime, anywhere.
LED Indicator Display: Equipped with intuitive LED lights that show the test status at a glance, making operation simple and clear.
Anti-misoperation Design: Built-in protection circuits prevent SIM card damage due to incorrect operation, ensuring safe testing.
General mobile phone maintenance fixture, rotary fixed design, no rebound, fixed firmly
Prevent clamps from moving during use, special anti-skid pad
Let the hot air be discharged more efficiently, and add a heat sink to the bottom of the clamp
The rotary shaft locks the motherboard or IC more efficiently, fixed well without a rebound
Fixtures also support IC-type fixtures fixed for the removal of back glue, the clamp is designed to bear the force of the IC beam, which can hold up the empty parts of the IC well and avoid the IC breaking when removing black glue
The fixture can be adjusted at different distances from the high, middle, and low levels. It's necessary to loosen the two screws at the bottom, move the fixing plate to the appropriate gear position, and then tighten the bottom screws to lock it
Protect the upper and lower layers of the double-layer motherboard during maintenance
Suitable for mobile phone motherboards of various sizes and shapes
