uSmart expansion connector can connect to the endoscope. Endoscope is a must have practical inspection tool for inspecting or repair work.
Designed with 1 camera on the front, this endoscope assists you to view thingsfrom more directions or angles.
Come with 6 adjustable LED lights around the camera so you can see clearly in dark with no worry. The light can be turned off.
The endoscope comes with semi-rigid cable, you can use the endoscope into many hard to reach, narrow and confined places at home or outdoors.
The endoscope equips small accessories for more functions: hook (catch items like keys, rings or jewelry), magnet (attract small iron items), protective case (protect the endoscope camera lens).
The working voltage is DC 10V-35V. It is recommended to use a switching power supply DC24V for power supply.
Using 6N137 high-speed optical coupling to ensure high speed without losing step.
Using Toshiba TB6560AHQ chip, there are built-in low-voltage shutdown, overheating shutdown and overcurrent protection circuits to ensure performance.
The rated output (max) is: +/-3A, with a vertex value of 3.5A.
It is suitable for two-phase/four-phase/four-wire/six-wire stepping motor with 42,57 stepping within 3A, but not suitable for stepping motor with more than 3A.
Automatic half-flow function.
Subdivision: Full step, half step, 1/8 step, 1/16 step, maximum 16 subdivision.
