DIY Parts & Components
Waveshare 25515 Round 2D Codes Scanner Module Barcode/QR Code Reader, With LED Indicator
- Suitable for barcode scanning applications such as elevators.
- Use advanced image recognition algorithms to easily decode various one-dimensional or two-dimensional codes.
- Onboard UART interface, which can be easily integrated into various embedded devices.
- Compact size and high integration
- Resolution: 640 x 480
- Scanning angle: horizontal 70 degrees, vertical 55 degrees, rolling 360 degrees
- Scan mode: induction, continuous
- Accuracy: one-dimensional code is greater than or equal to 5mil, two-dimensional code is greater than or equal to 10mil
$29.17 $34.42
PAM8403 Mini 5V Digital Amplifier Board USB Power Supply Good Sound Effect, Specification: With Potentiometer
- Power supply range: 5V DC
- Operating voltage: 2.5V-5.5V
- Output Power: 3W x 2 (5V 4)
- PAM8403 is a small digital amplifier chip, high-definition sound quality highlights the advantages of digital chips
- Circuit using a reasonable peripheral configuration, power supply filter upgrade to 470uf, 1.6mm fiberglass plate, the amplifier board to do the meticulous
- Output 3W + 3W high-fidelity sound quality, potentiometer using the original anti-surface body, life expectancy of up to 15 years, potentiometer with a switch can be counterclockwise directly cut off the power supply.
- Please ensure that the power supply voltage does not exceed 5.5V, and please do not reverse the positive (+) negative (-) polarity, otherwise it will burn the circuit board!
- Size: with potentiometer about 29.5 x 20.2 x 15 mm, module about 21 x 18 mm
$4.80 $5.90
DC 6-28V 3A PWM Speed Adjustable Reversible Switch DC Motor Driver Reversing
- The 1203BB DC motor speed regulator controls the speed of the DC motor by adjusting pulse width modulation (PWM). It provides 3A of continuous current to your DC motor or other DC load.
- The circuit contains a 3A fuse for reverse power supply, and controls the forward, reverse, and stop of the DC motor through a switch.
- Material: metal
- Input voltage: DC 6-28V
- Dimensions: 5 x 3.2 x 1.5cm
- Weight: 30g
- Instructions:
- Make sure the power is off before trying to connect the controller.
$6.17 $7.28
TPA3118 PBTL 8-24V Mono Digital Amplifier Board 60W
- The sound quality using this module is very good.
- Mono digital audio amplifier chip.
- High output and low power consumption.
- Applicable speaker impedance: 4-8 ohms (8 ohms is best).
- Product specifications:
- Power amplifier chip: TPA3118
- Working voltage: DC8-24V
- Output power: 60W/30W
$6.13 $7.42
3S 3.7V 12V 100A Polymer Li-ion Phosphate Battery Protection Board With Balance
- Lithium battery protection board specially designed for lithium phosphate, ternary lithium battery, lithium cobalt oxide, and lithium manganate battery packs.
- Adopt mature protection circuit, IC and support disconnection protection, imported high-current internal resistance MOS (single MOS internal resistance 3 milliohms), with complete and stable charging and discharging various protection functions, battery core hardware balancing processing, balancing current Appropriate, balanced heating is reasonable and does not affect battery pack performance.
- Output current: 80A for separate port; 60A for same port
- We have protective boards with two parameters: lithium iron phosphate and polymer. If your battery is lithium iron phosphate with a nominal 3.2V single cell, you need to select lithium iron phosphate 3.2V in the category. If it is polymer (ternary) , cobalt acid, lithium manganate battery) single battery nominal 3.6V (or 3.7V) please choose the polymer 3.7V classification.
- Working temperature: -20-65 degrees Celsius
$6.60 $7.79
60V Step-Down Power Module 12A High Power CNC Converter
- Input voltage range: 10V-75V
- Output voltage adjustment range: 0-60V
- Output current adjustment range: 0-12A
- Output power: 0-720W
- Output voltage setting resolution: 10mV
- Output current setting resolution: 10mA
- Output ripple: 50mVpp (input 54V, output 30V, current 5A)
- Storage operation: M0-M9 total 10 groups of parameters storage
$28.80 $35.71
TB6560 3A 10V-35V Stepper Motor Driver Controller Board (Green)
- The working voltage is DC 10V-35V. It is recommended to use a switching power supply DC24V for power supply.
- Using 6N137 high-speed optical coupling to ensure high speed without losing step.
- Using Toshiba TB6560AHQ chip, there are built-in low-voltage shutdown, overheating shutdown and overcurrent protection circuits to ensure performance.
- The rated output (max) is: +/-3A, with a vertex value of 3.5A.
- It is suitable for two-phase/four-phase/four-wire/six-wire stepping motor with 42,57 stepping within 3A, but not suitable for stepping motor with more than 3A.
- Automatic half-flow function.
- Subdivision: Full step, half step, 1/8 step, 1/16 step, maximum 16 subdivision.
- Dimensions: Width 50 x length 75 x height 35 (MM)
$10.53 $12.32
2 PCS HW-134A A4988 Red Board Stepper Motor Driver Module Heat Sink for 3D Printer
- Features: Higher copper content, good heat dissipation performance, strong current stability
- Manufacturing process: SMT placement machine manufacturing, non-manual welding, higher yield rate, more stable performance
- Remarks:
- A single-head printer requires 4 A4988 modules.
- A set of dual-nozzle printer requires 5 A4988 modules.
- Delivery list: A4988 module x 1, heat sink aluminum sheet x 1
- Matters needing attention: Please do not plug and unplug the motor and drive when the power is on, which will easily cause the drive to burn out; also do not adjust the current when the motor is running. The correct way is to first disconnect the power supply, unplug the motor, and then power on again, adjust the potentiometer, and measure the voltage on the potentiometer until the measured voltage is the same as expected. Do not plug in the reverse drive, otherwise it will burn out the drive and even the motherboard
$7.84 $9.02
Waveshare 26369 1.28-Inch Round LCD Screen RP2040 MCU Board without Touch
- Non-touch version features:
- RP2040 microcontroller chip designed by Raspberry Pi
- Equipped with dual-core ARM Cortex M0+ processor, running frequency up to 133MHz flexible clock
- Built-in 264KB SRAM and 2MB onboard Flash
- Adopt Type-C interface, no need to worry about forward and reverse insertion
- Onboard 1.28-inch 240240 resolution, 65K color IPS LCD display, can clearly display color pictures
- Onboard lithium battery charging and discharging interface, which is conducive to mobile scene use
- The upper shell is made of CNC metal material, and the back is equipped with acrylic frosted bottom plate
$34.17 $41.69
Waveshare 26369 1.28-Inch Round LCD Screen RP2040 MCU Board with Touch
- Touch version features:
- RP2040 microcontroller chip designed with Raspberry Pi
- Equipped with dual-core ARM Cortex MO0+ processor, running at up to 133MHz flexible clock
- Built-in 264KB SRAM and 16GB onboard Flash
- Adopts Type-C interface, no need to worry about whether to insert it forward or backward
- Onboard 1.28-inch capacitive touch LCD screen, 240240 resolution, 65K color
- Onboard lithium battery charging and discharging interface, which is conducive to mobile scene use
- The upper shell is made of CNC metal material, and the back is equipped with an acrylic frosted bottom plate
$34.12 $39.58
Waveshare Barcode Scanner Module, 1D/2D Codes Reader
- Overview
- 1. This is a small 1D/2D codes reader, by using the intelligent image recognition algorithm, it will decode the barcode or 2D code on paper or screen, fast and accurately.
- Through the onboard USB and UART interface, it can be directly plugged into a computer, or be easily integrated to kinds of devices due to its small form factor.
- Features
- 1. Easy to use, requires no knowledges of image recognition
- Decodes various common 1D/2D codes such as Barcode, QR code etc.
- Onboard micro USB and UART serial port, allows to connect with computers or embedded devices
- Configurable via scanning 'configuration code'
$39.26 $45.54
Waveshare PCF8591 AD DA Board
- Overview
- 1. The PCF8591 AD DA Board features an 8-bit A/D Converter & D/A Converter PCF8591 with four analog inputs, one analog output and a serial I2C-bus interface.
- The PCF8591 AD DA Board features I2C pinheader on one side, and I2C connector on the opposite side. Hence, its more flexible to connect the board to your development system. The board also supports I2C cascading, allowing the use of multi module connected to the I2C bus at the same time by connecting the pinheader and connector.
- Features
- PCF8591, I2C pinheader, I2C connector, Adjustable resistor, Analog input for A/Dconversion, Analog output for D/A conversion, Address pins jumper
$11.62 $13.36
