Charging indication: the charging display will show IN letters
Output load indication: long press the LED button after connecting the load, the output will start, the display will show OUT letters and the relative output voltage and current 5V1A or 5V2.1A
Protection function: the protection circuit of the boosted lithium battery has been integrated to prevent over-discharge, overcharge and overload
Note: B+ and B- connected to the boosted battery must not be reversed, reverse must burn, can be connected to a lithium-ion battery can also be connected in parallel with a number of lithium-ion battery
Capacity of not more than 200,000 mAh, voltage 3-4.2V can be used, lithium positive pole connected to B +, lithium negative pole connected to B-
This product has voltage display function and USB output (mobile phone charging) function. It has only two wires and is simple to connect. It can be used for DC power supply or 12V or 24V battery in the voltage range of 8-40V. The two USB ports can output 5V2A, automatically distribute output current
PAM8403 is a small digital amplifier chip, high-definition sound quality highlights the advantages of digital chips
Circuit using a reasonable peripheral configuration, power supply filter upgrade to 470uf, 1.6mm fiberglass plate, the amplifier board to do the meticulous
Output 3W + 3W high-fidelity sound quality, potentiometer using the original anti-surface body, life expectancy of up to 15 years, potentiometer with a switch can be counterclockwise directly cut off the power supply.
Please ensure that the power supply voltage does not exceed 5.5V, and please do not reverse the positive (+) negative (-) polarity, otherwise it will burn the circuit board!
Size: with potentiometer about 29.5 x 20.2 x 15 mm, module about 21 x 18 mm
